The test machine is to simulate the daily use of the process of loading the seat on the seat and back to test the durability.



Application:

The Chair tester tests the strength and durability of the seats and backrests by simulating the routine use loading of the seat.

The Chair Seating and Back Testing Machine is equipped with two drive units, and can be individually controlled to repeatedly load the test points of the seat. Through different parameter settings, the machine can complete the following types of test functions on the seat:
1. Seat and back static load test.
2. Seat and back durability test.
3. Seat front edge static load and durability tests;
4. Horizontal forward static loading test for backrest.
5. Headrest static load test,
6. Legs forward static load test,
7. Leg lateral direction static load test.
If the customer additionally purchases the GT-LB01-7 impact hammer for the machine, the following tests can be added: Backrest impact test, armrest impact test.

Feature:

1. The main structure of the machine is made of aluminum, beautiful and easy to maintain.

2. Servo motor drive, test loading control is more accurate, and the noise is even smaller.

3. Chair Seating and Back Testing Machine: PLC touch screen control makes the operation more convenient.

4. In addition, the machine loading device using electric control movements, more extensive test space.

Model GT-LB04-1
Working position 1
Seat surface load capacity 2000N
backrest load capacity 2000N
Seat surface height 15 – 70cm
Testing time 0-99999 ( can be adjustment)
Control method PLC touch screen control
Lifting method Automatic lifting
Power 1 phase AC 220V 50/60Hz
Dimension (WxDxH) 180x150x200cm
Weight 500kg
Standard Accessories GT-LB01-1A Loading point template   1 pc
GT-LB01-2A Seat loading pad    1 pc
GT-LB01-3 Smaller seat loading pad    1 pc
GT-LB01-4 Back loading pad    1 pc
GT-LB01-5 Local loading pad    1 pc
Stationary fixture    1 pc
Stops    1 pc
Optional Accessories GT-LB01-7 Impact hammer
GT-LB01-1B Loading point template
GT-LB01-2B Seat loading pad
GT-LB01-10 BIFMA cumulative Weight
