Fiber Fineness Meter

Model :T245

Fiber fineness meter uses vibroscope method to determine the linear density of textile fibers applicable to bundles of fibers and individual fibers. By the principle of string vibration, the vibrating fineness meter can measure the natural vibration frequency under a certain length and tension and provide fiber linear density after automatic calculation of string vibration formula. It is applicable for natural fiber or man-made fiber, short fibers or long fibers.



Inquire Now

Overview

The fiber tensile tester can work with vibrating fiber fineness meter to provide fiber strength, fiber linear density, strength ratio, initial modulus, specific work to rapture and other performance parameters of fiber. Tensile tester-vibrating fineness meter accords with the recommended method of BISFA (Bureau International pour la Standardization des Fibers Artificielles).

Feature

  • Fast and stable performance.
  • Not only linear density, but also density irregularity with quality distribution.
  • Microprocessor controlled system with self-excited oscillation principle raise the test precision.
  • Simple auto operation mode can reduce the artificial test error.
  • User-friendly interface supports data analysis, data storage, report output and others.
  • Integrated software is compatible with different testing units.



Specification

  1. Linear density range : 0.6～40 dtex
  2. Density measuring error :≤±2％
  3. Clamping length :20mm
  4. Length error :≤±1％
  5. Pre-clamping force accuracy :≤±0.5％
  6. Frequency measuring error :≤±0.5％
  7. Power supply :220V 50Hz
  8. Dimension :393mm×300mm×320mm
  9. Net weight :10kg

Standards

GB/T 14335   GB/T 16256   ISO 1973   BISFA

Configuration

No. Product
2024501 Fiber fineness meter
2024502 Analyzing software
2024503 Computer
2024501 Fiber tensile tester
