Quick Dry Rate Tester

Quick Dry Rate Tester

Model :T369
Quick dry rate tester is professional designed to determine the dry rate of fabric, which is exposed to a prescribed volume of water, tested surface temperature change, and time of drying. The tester is based on the heated plate method to determine the dry rate. It is applicable to all types of fabrics, including knits, woven, and non-woven, as well as to fabrics taken from end product items.
Inquire Now

Feature

  • Pre-programmable controller with color screen interface on the tester.
  • Wifi testing results and data outputting.
  • Aluminous body provides resistance to corrosion and durability.

Standard

AATCC 201

Specification

  1. Heated plate : 305mm×305mm
  2. Specimen holder : 150mm×40mm×2mm
  3. Temperature : 37 ± 0.1 ºC
  4. Air flow :1.5m/s ± 0.1m/s
  5. Temperature sensor : IR Thermocouple
  6. Temperature range : 15~50ºC ± 0.1 ºC
  7. Sample thickness : Up to 10mm
  8. Water volume :Adjustable 0.2ml ± 0.001ml
  9. Power supply : 220V 50Hz
  10. Dimension :520mm×400mm×300mm
  11. Net weight :35kg

Configuration

No. Product
2036901 Quick dry rate tester
2036902 Laptop with analysis software
