Description

Features

• Embedded system, easy to remote maintenance and upgrade
• Patent technology design
• Touch screen operation
• Real color TFT LCD display
• 6 independent test stations in one
• Embedded proximity sensor, auto start test and auto stop
• Precise time control along with wide timer range
• Designed based on various standards
• Various temperature test

Technical indexes

• Temperature Range: room temperature–200℃ (standard)
• Temperature Accuracy: 0.1℃
• Test Mass: 1000g (triangle hook included)
  4500g (optional)
• Timer Range: 0 – 10,000h
• Timer Step: 1sec
• Test Panel: 125mm (L)×50mm (B)×2.0mm (D)125mm (L)×50mm (B)×2.0mm (D) with 120°bend (optional)
• Test Station: 6, independent
• Roller Weight: 2000g ± 50g
• Dimension: 696mm (L)×510mm (B)×557mm (H)
• Power: AC 220V 50Hz
• Net Weight: 67kg

Standard

ASTM D3654, PSTC 107, GB 4851, JIS Z0237

Configuration

Standard Configuration: mainframe, roller, test panel(stainless steel), test mass, power line.
Optional: load mass(non-standard).
