Model :T392
Textile formaldehyde meter which is also called textile or fabric formaldehyde tester is to determine the amount of free formaldehyde and formaldehyde extracted partly through hydrolysis by means of a water extraction method. The tester can also be used to determine the release formaldehyde by means of vapor absorption method.
Description
Feature
- Double control of tester and computer provides automatic data analysis.
- Free chosen of wavelength, absorbance, absorption curve and transmittance.
- Automatic calculation for 100% and 0%.
Standards
ISO 14148-1 ISO 14148-2 AATCC 112 GB/T 2912.1 GB/T 2912.2 GB 18401 SN/T 2195
Specification
| Testing range | 5.00–500.00 mg/kg (Sample diluted up to 5000 mg/kg) |
| Transmittance | 0%–100% |
| Absorbance | 0–2.0 |
| Light source | Tungsten halogen lamp |
| Wavelength | 325–1100 nm |
| Spectral bandwidth | 2 nm |
| Light system | Automatic calibration light path |
| Wavelength accuracy | ±1 nm |
| Wavelength repeatability | ±0.5 nm |
| Power supply | 220V 50Hz |
| Dimension | 400mm × 300mm × 200mm |
| Net weight | 15 kg |
Configuration
| No. | Product |
| 2039201 | Textile formaldehyde meter |
| 2039202 | Computer with analysis software |
| 2039203 | Testing kit |
