Product Description
EORT-V/HASS Comprehensive Environmental Test Chamber cover temperature,humidity, thermal shock with rapid temperature change rate, vibration testing. It has been respected by most advanced industries since its inception.
Companies using EORT-V Chamber are very satisfied with the screening results of product defect rates through EOS-V Chamber. Through screening data analysis, they believe that products can be quickly changed in temperature and humidity, and Under the comprehensive test of multi-axis vibration, the service life and potential defects of the product at the beginning of production or development can be screened out, because the defects will be quickly exposed under the comprehensive action of temperature and mechanics.
The EOST-V Chamber is increasingly recognized and valued by more electronics, Netcom, and other similar industries. Rage, in order to evaluate the performance of the sample under given environmental conditions.
Product Usage
The simulation product detects whether the adaptability and characteristics of the product itself have changed under the combined conditions of temperature and humidity in the climate environment (high and low temperature operation & storage, temperature cycle, high temperature and high humidity, low temperature and low humidity, condensation experiment. etc.).
Need to meet the requirements of international standards (IEC, JIS, GB, MIL…) to achieve international consistency in measurement procedures (including test procedures, conditions, and methods) to avoid differences in perception and reduce the range of uncertain factors in measurement occur.
Test chamber technical specification:
| Working volume |
512L |
| Model |
SM-EORT-V-512 |
| Inner chamber size |
W800 mm×D800 mm×H800 mm |
| Outer chamber size： |
According to the drawing, to be confirmed |
| Weight |
1650kgs |
| Ambient conditions |
The ambient temperature is +25℃, the relative humidity is ≤85%, no load |
| Temperature test range |
-40℃～150℃。 |
| Humidity test range |
15% ～ 98%RH 。 |
※Please consult the sales for specific technical parameters, SANWOOD reserves the right of explanation.
