Model :T305
Gakusin rubbing fastness tester which is also called as JIS rubbing fastness tester is professional designed to determine the resistance of the color of the dyed textiles to rubbing. The tester can provide certain loads and rubbing effects on the samples for helping color fastness assessed by comparing the staining of the undyed cotton cloth with the grey scale for assessing staining. It is widely applicable for textiles, synthetic leather, board, paintings or print ink on color fastness performance or abrasion resistance property.

Feature

  • Six individual testing positions.
  • LCD digital presetting counter with automatic stop.
  • High efficiency motor with low noise.

Specification

  1. Rubbing finger :20mm×20mm
  2. Finger surface :Curved surface with r45mm
  3. Rubbing finger mass :200g
  4. Specimen stage :Curved surface with r200mm
  5. Rubbing distance :100mm
  6. Reciprocating rate :30 cycles/min
  7. Power supply :220V 50-60 Hz
  8. Dimensions :490mm×550mm×365mm
  9. Net weight :45 kg

Standard

JIS L0849

Configuration

No. Product
2030501 Gakusin rubbing fastness tester
2030502 Loading weight kit
