Horizontal Flammability Tester

Model :T386

Horizontal flame resistance tester is design based on FMVSS 302 to determine the burning behavior of materials as interior in motor vehicles by calculating the burning rate of the specimen after ignition by a small flame. Exposed to a certain flame for specified time, the specimen which is clamped in a U shape holder will be measured for the burned distance and time taken to burn this distance. The tester is particularly important for assessing safety of the materials used in the passenger compartment.

Feature

  1. Automatic counter without manual counting.
  2. Automatic stop after testing is more safe and convenient.
  3. Wireless timer controller is designed for the fuming hood.
  4. Heat resistant glass observation window.

Specification

Item Detail
Height of flame 10-200mm
Exposing time 0-99.59s
Afterflame time 0-99h59m59.9s
Resolution 0.01s
Power supply 220V 50Hz
Dimension 400mm×215mm×540mm
15.75inch×8.46inch×21.26inch
Net weight 32kg
70.55lb

Standards

GB 8410  ASTM D5132  SAE J369  FMVSS 302  ISO 17074  ISO 3795  DIN 75200



Configuration

No. Product
2038601 Horizontal flame resistance tester
2038602 Sample holder
2038603 Flame height gauge
