ICI Pilling and Snagging Tester

Model :T321
ICI pilling and snagging tester is to determine the resistance to pilling and surface change of textile fabrics. Specimens are mounted on polyurethane tubes and tumbled randomly in a cork-lined box at a constant rotational speed. The tester can use to determine the propensity of fabrics to snagging and relative surface defects with exchangeable octagonal snagging drum. Pilling and snagging is assessed visually after a defined period of tumbling.
Inquire Now

Feature

  • Preset testing cycles with automatic stop make tests easier.
  • High quality motor provides lower running sound and longer service life.
  • User friendly loading and unloading structures design for testing drums makes changing drums for different tests more convenient.



Specification

  1. Testing position :2 or 4
  2. Rotational speed :(60±2)rpm
  3. Terminal point :Automatic stop with buzzer alarm
  4. Pilling box :235mm for internal dimensions before lining
  5. Power supply :220V  50Hz
  6. Dimension :840mm×580mm×560mm
  7. Net weight :55kg

Standards

GB/T 4802.3  BS EN ISO 12945.1  BS 8479  BS 5811  IWS TM152  NEXT TM19  M&S P18 M&S P18A  M&S P18B  M&S P21A

Configuration

No. Product
2032101 ICI pilling and snagging tester (4 Drum)
2032102 ICI pilling and snagging tester (2 Drum)
2032103 Octagonal snagging drum
2032104 Mounting jig
2032105 Viewing cabinet/Assessment Viewer
2032106 PVC tape
2032107 PU specimen tube
2032108 Cork lining
2032109 Snagging points
2032110 Pilling photographs
