Sublimation Fastness Tester

Model :T304
Sublimation tester or scorch tester is the recommended testing instrument for textile color fastness to hot pressing, chlorine retained and tensile loss. The tester suits for the method for determining the resistance of the color of textiles of all kinds and in all forms to ironing and to processing on hot cylinders. It also can be used to measurement the dimension change after hot pressing.
Inquire Now

Feature

  • Color touch screen is easy to operate.
  • Individual control for each heating panel.
  • PID temperature controller is reliable.

Specification

  1. Position : One or Three
  2. Heating panel : Upper and lower heating panel
  3. Panel dimension : 50mm×110mm
  4. Timer : 1-999s
  5. Pressure : 4kPa±1kPa
  6. Temperature range : Up to 250℃
  7. Power supply : 220V 50Hz
  8. Dimension : 520mm×540mm×320mm
  9.  Net weight : 18.5kg

Standard

ISO 105 P01  ISO 105 X11  AATCC 117  AATCC 133  M&S C13  M&S C10  GB/T 5718  GB/T 6152  JIS L0879  JIS L0850
